2024 TRUVAC HXX

Chassis

• Model: Kenworth T440

• Toolboxes:

  • Driver Side Chassis Frame: 48"W x 20"H x 30"D

  • Passenger Side Chassis Frame: 48"W x 20"H x 30"D

  • Passenger Side Subframe (in lieu of Tool Tray): 104"W x 24"H x 22"D

• Circuit Breakers

Vacuum & Debris System

• Vacuum Blower: Roots 824RCS/18

• Vacuum System: 8" ID with Vacuum Relief

• Debris Tank: 12 yd³ Extended Steel Body

• Dump Hoist: Double Acting

• Cyclone Separator: Single with Cyclone Drain Valve

• Debris Body Features:

  • Deflectors

  • Electric Vibrator

  • S.S. Float Ball Shut-Off

  • Air Purge

  • Splash Shield

  • 8" Inspection Port with Ladder

  • Flat Rear Door with Hydraulic Locks and Lift

  • Knife Valves with Camloc (6" at 3:00 and 6:00 Positions)

• Debris Body Indicators:

  • Body Out of Position Alarm

  • Electronic Back-Up Alarm

• DigRight® Technology

Water System

• Tank Capacity: 1200 gallons total (including 200-gallon poly heated tank)

• Water Heater: 800,000 BTU – 12V

• Pump: 20 GPM / 3000 PSI (in lieu of 10 GPM)

• Controls:

  • Multi-Flow System

  • Electronic Low Water Indicator

  • Remote Heated Drain Valve

• Water Fill & Drain:

  • 2" Y-Strainer with 25' Fill Hose

  • 2.5" Cam-Lok Fill Fittings

  • 3" Drain

• Water Accessories:

  • Handgun Kit (5 GPM / 10 GPM)

  • 75' Retractable Handgun Reel

  • Hydroexcavating Nozzles (incl. Single Jet Spinner)

  • 3 Fixed Jet Nozzles + 4 Vactor Rotator Nozzles

Boom System

• Boom Type: 7 ft. Telescoping, 320° Rotation

• Features:

  • Hard Hat Style Elbow

  • Removable Turret Box

  • Boom Out of Position Alarm

  • Manual Hydraulic Override Pump

• Control:

  • Wireless Remote w/ Pump & Vacuum Relief

  • Boom Control Panel

  • Second Operator Station (Front)

Cold Weather & Insulation

• Cold Weather Package 3:

  • Includes FEPTO Recirculator & Antifreeze Tank

• Water Tank: Glycol Heated & Foil-Backed Closed Cell Insulated

• Heated Drain Valve: Remote Mounted

Control & Electrical

• Control Panels:

  • Front Station Control

  • Control Cabinet Toolbox: 36"W x 24"H x 12"D

  • Water Pump Cabinet Toolbox: 50"W x 30"H x 30"D

• Electrical System: Fully Sealed

• Back-Up Systems:

  • Electronic Back-Up Alarm

  • Wireless Remote Controls

Storage & Accessories

• Pipe Racks:

  • Folding Curbside

  • Folding Rear Door

• Additional Toolboxes:

  • Water Tank Toolbox (Driver Side): 48"W x 24"H x 12"D

• Lube Manifold

• Hydraulic Tank Shut-Off Valves

• Hydrant Wrench/Tool Package

Lighting & Camera

• Lighting:

  • Rear & Front LED Beacon Lights with Limb Guards

  • (2) Boom Work Lights

• Camera: Rear Only
